🚀 GAMDIAS ATHENA P3 E-ATX Mid-Tower Chassis

The GAMDIAS ATHENA P3 redefines high-performance PC design. 🔥 Blending its striking dual-tone bar-patterned mesh front panel with a massive interior layout, this mid-tower chassis easily accommodates E-ATX motherboards and next-gen flagship graphics cards. 🛒 Equipped with four pre-installed 140mm PWM fans and an internal 8-port ARGB control hub, it delivers exceptional, focused thermal efficiency right out of the box! 💨

💡 Key Selling Point: Fully supports BTF / Connector-Hidden motherboards (such as ASUS BTF and MSI Project Zero), allowing all cables to plug securely into the back of the motherboard tray for a completely clean, wire-free front chamber view! 💎

🛠️ Technical Specifications

🖥️ Core Overview

• Case Type: Mid-Tower

• Chassis Color: Black 🖤 (Dual-Shade Harmony with graphite grey accents)

• Materials: SPCC Steel, ABS Plastic, & Tempered Glass

• Side Window: Left Side Premium Tempered Glass Panel 🔬

• Motherboard Support: E-ATX, ATX, Micro-ATX, Mini-ITX 🧩

• Expansion Slots: 7

📏 Hardware Clearance

• Max GPU / VGA Length: Up to 430 mm (Fits largest NVIDIA RTX 50-series / 40-series cards easily) 🎮

• Max CPU Cooler Height: Up to 180 mm 🧊

• Max PSU Length: Up to 220 mm 🔌

🌊 Cooling & Radiator Support

• Front Radiator Support: 420 mm / 280 mm

• Top Radiator Support: 360 mm / 280 mm 🛠️ (Supports front 420mm and top 360mm radiators simultaneously)

• Rear Radiator Support: 140 mm / 120 mm

💨 Fan Support Configuration (Up to 9 Fans)

• Front: 3 × 140mm or 3 × 120mm (3 × 140mm Performance PWM Fans Pre-installed) ✨

• Top: 3 × 140mm or 3 × 120mm

• Rear: 1 × 140mm or 1 × 120mm (1 × 140mm Performance PWM Fan Pre-installed) ✨

• Bottom (PSU Shroud): 2 × 140mm or 2 × 120mm

💾 Storage & Drive Bays

• Drive Options: 📦

  • 2 × 3.5" or 2 × 2.5" + 1 × 3.5" (via removable HDD Cage)

  • 1 × 2.5" (via dedicated SSD Bracket)

🔌 Top I/O Interface Ports

• 1 × USB 3.2 Gen 2 Type-C (Up to 10 Gbps speeds) ⚡

• 2 × USB 3.0 Type-A 🟦

• 1 × HD Audio Jack 🎧

• 1 × LED Control Button 💡

🎛️ Included Control Hardware

• Built-in Hub: Pre-installed 8-Port PWM ARGB Fan Control Box (4 ports utilized by default for factory fans) ⚙️

• RGB Sync: 5V 3-Pin Addressable Header for motherboard software synchronization 🌈

• Dust Filters: Top, Side, and Bottom removable filters for fast maintenance 🧼

📐 Physical Dimensions

• Chassis Dimensions (L x W x H): 500 × 238 × 500 mm

🎯 3 Reasons to Build in the ATHENA P3

1. Zero Airflow Leaks 💨: Features a unique, integrated gap-bridging bracket directly behind the front panel. It seals the space between the mesh and the fan mounts, ensuring intake air is forced straight through your components without escaping into the side gaps!

2. Ready for Next-Gen Motherboards 🧩: If you are planning a modern, ultra-clean setup, the specialized cutouts cleanly route back-connect motherboards (BTF/Project Zero) with plenty of clearance behind the tray.

3. True Flagship Room 📐: At 238mm wide, it provides exceptional lateral clearance—ensuring massive, power-hungry premium GPUs don't bend your 12V-2x6 power cables aggressively against the glass side panel!
