⚡ CyberPower Value2200ELCD UPS – Specification

General

• Topology: Line-interactive UPS

• Form Factor: Tower

• Output Type: Simulated sine wave

• AVR: Single Boost & Single Buck

Capacity

• Rated Capacity: 2200 VA / 1320 W

Input

• Nominal Voltage: 230 VAC ± 10%

• Voltage Range: 165 – 280 VAC

• Frequency: 50 Hz ± 5% / 60 Hz ± 5% (auto detect)

• Rated Input Current: 10 A

Output

• On-Battery Voltage: 230 VAC ± 10%

• On-Battery Frequency: 50 Hz or 60 Hz ± 1%

• Transfer Time: ~4 ms

• Overload Protection: Internal Circuit Breaker

• Outlets: 4 outlets (AS/AU type) or up to 6 IEC C13 (regional variant)

Battery

• Type: Sealed Lead-Acid, maintenance-free

• Configuration: 2 × 12 V 9 Ah

• Typical Recharge Time: ~8 hours

• Runtime:

  • 7–8 minutes @ half load

  • 1–2 minutes @ full load

• User-replaceable: Yes

Protection & Filtering

• Surge Protection: Yes (125–150 J depending on SKU)

• EMI/RFI Filtration: Integrated

• Phone/Network Protection: RJ-11 / RJ-45 combo

Management & Interface

• LCD Display: Multifunction – input/output voltage, load %, battery level, alarms

• Alarms: Audible alerts (battery, low battery, overload, fault)

• Ports: USB (HID-compliant), Serial (DB-9, region dependent)

• Software: PowerPanel® Personal Edition

Physical

• Dimensions: 140 × 180 × 326 mm (W × H × D)

• Weight: ~14.5 kg
